| GSM 10 | GSM 13 | GSM 16 | ||||
|---|---|---|---|---|---|---|
| MACHINING AREA | ||||||
| Swing over bed, carriage and steady-rests | mm | ∅ 1000 | ∅ 1300 | ∅ 1600 | ||
| Distance between centers | mm | Up to 8000 | Up to 12000 | Up to 13000 | ||
| Y-axis stroke | mm | -1 | -1 | -1.142857143 | ||
Swing over bed : ∅ 1300 mm
Swing over carriage : ∅ 1000 mm
Motor power S1/S6 : 28/34 [39/48] kW
Range of speeds : 0÷1000* rpm
More info
Travels X Axis : 1400 mm
Z Axis : 1200 mm
B Axis : 360°
Tool capacity (opt.): : 60 nr
More info
X Axis : 560 mm
Z Axis : 660 mm
Y Axis : 640 mm
Spindle speed (opt.) : 15000 min-1"
